GOT318WL-845

18.5" WXGA TFT Multi-touch Panel Computer with Intel® Pentium® Processor N3710

  • 18.5" WXGA multi-touch projected capacitive widescreen or flat resistive touch (optional)
  • Fanless design with Intel® Pentium® processor N3710
  • 2.5" SATA HDD & mSATA
  • 3G, WLAN module & antennas (optional)
  • 2 GbE LANs, 2 USB 3.0, 2 USB 2.0 and 2 COM
  • IP65-rated aluminum front bezel
  • Supports panel mount and VESA mount (VESA arm/desktop stand/wall mount optional)
  • Adjustable RS-232/422/485 setting via BIOS

The GOT318WL-845-PCT is powered by the Intel® Pentium® N3710 processor with fanless design and low power consumption. To provide excellent user experience, this WXGA industrial grade touch panel PC adopts an 18.5-inch screen with a 16:9 widescreen display; moreover, it offers options for 10-point multi-touch projected capacitive touch or 5-wire flat resistive touch. The slim size extends the flexibility for fast and easy project development and deployment. In addition, this heavy-duty 18.5-inch touch panel PC has several feature highlights to stabilize operation in ruggedized environments - an IP65-rated dust or liquid spillage-proof front bezel, a wide operating temperature range of 0°C to +50°C, and up to 1G vibration endurance. The Intel® Atom-based panel unit with integrated Intel® HD onboard graphics can display content in HD resolution making it perfect for infotainment and self-service kiosk in retail. Teaming high performance and advanced features with friendly operation, this 18.5-inch multi-touch IP65 panel PC is well-suited for transportation, heavy-duty industry, smart factory automation, oil monitoring systems, and smart retail.

LCD Panel
  • 18.5" WXGA TFT LCD
  • 250 nits
  • 1366 x 768 pixels
CPU
  • Intel® Pentium® processor N3710 1.6 GHz (Braswell)
Chipset
  • SoC integrated
System Memory
  • 1 x 204-pin SO-DIMM DDR3L-1333/1600 , up to 8GB
BIOS
  • AMI
COM
  • 1 x RS-232
  • 1 x RS-232/422/485
USB
  • 2 x USB 3.0
  • 2 x USB 2.0
Ethernet
  • 2 x 10/100/1000 Mbps (Intel® i211-AT)
Display
  • N/A
Audio
  • 1 x Audio (Line-out)
Storage
  • 1 x 2.5" SATA HDD (9.5 mm height)
  • 1 x mSATA
Expansion
  • 1 x full-size PCI Express Mini Card slot with mSATA
  • 1 x full-size PCI Express Mini Card slot with SIM
Others
  • 1 x switch for power on/off (ATX)
Touchscreen
  • Projected capacitive multi-touch
  • Flat resistive touch (optional)
Front Bezel
  • IP65 front bezel
Power Supply
  • DC version: 24 VDC
Power Comsumption
  • 48 W
Watchdog Timer
  • 255 levels, 0 ~ 255 sec.
Operating Temperature
  • 0°C to +50°C (+32°F to +122°F)
Relative Humidity
  • 20% to 90% @ +40°C; non-condensing
Vibration
  • 1G, 10 - 500 Hz, random for 2.5" SATA HDD
Dimensions
(W x D x H)
  • 460.8 x 58.5 x 285 mm (18.11" x 2.3" x 11.22")
Weight (net/gross)
  • 5.8 kg (12.8 lb)/8.2 kg (18.1 lb)
Certifications
  • CE
EOS
  • Windows® 10 IoT Enterprise, Windows® 10
Mounting
  • Panel mount
  • VESA arm
  • Desktop stand
  • Wall mount
  • GOT318WL-845-PCT-DC
  • 18.5" WXGA TFT fanless touch panel computer with Intel® Pentium® N3710 1.6 GHz quad core processor, projected capacitive multi-touch screen and 24 VDC terminal block connector
  • Wi-Fi
  • 4G
  • 82231770050E
  • GOT3177T-834 wall mount kit
  • 50906D24000E
  • Adaptor 24V/120W, wire only, FSP120-AAAN3
