GOT710S-837

10.4" SVGA TFT LCD Railway Fanless Touchscreen Panel PC with Intel® Atom™ Processor E3845 1.91 GHz (-40°C to +70°C)

Features

  • Sunlight readable 10.4" SVGA TFT LCD with 1000 nits of brightness
  • Intel® Atom™ processor E3845 1.91 GHz
  • Alternative keypad control in the front bezel
  • M12-type lockable connectors design
  • Auto-dimming for different environments
  • -40°C to +70°C wide temperature range
  • EN 50155, EN 45545-2 certified for railway application
  • Typical 24 to 110Vdc power input, EN 50155 Class S3
  • 20ms power interruption protection

Datasheed (PDF)

LCD Panel
  • 10.4" TFT LCD
  • 1000 nits
  • 800 x 600 pixels
CPU
  • Intel® Atom™ processor E3845 1.91 GHz (Bay Trail)
Chipset
  • SoC integrated
System Memory
  • DDR3L 4GB onboard
BIOS
  • AMI
COM
  • 2 x Isolated M12 A-coded RS-232/422/485 (isolation level 1.5kV)
USB
  • 1 x M12 A-coded USB 2.0 (2 port signal)
Ethernet
  • 2 x isolated M12 X-coded GbE (isolation level 1.5kV)
Display
  • N/A
Audio
  • 1 x DB15 audio (line-in/mic-in/speaker-out/line-out)
Storage
  • 16GB flash onboard
  • 1 x mSATA
Expansion
  • 2 x PCI Express Mini Card slot
Others
  • 1 x M12 A-coded DC-in
  • 1 x Isolated terminal block DIO (6-in/2-out, isolation level 1.5kV)
  • 1 x Isolated DB9 CANbus (isolation level 1.5kV)
Touchscreen
  • Alternative 5-wire resistive touchscreen or keyboard
Front Bezel
  • IP65, NEMA 4 rugged protection, aluminum front bezel
Power Supply
  • Typical 24 to 110 VDC, working range 16.8 to 137.5 VDC,
  • EN 50155 Class S3 20ms power interruption protection
Power Comsumption
  • 24-110V@1.4-0.29A
Watchdog Timer
  • 255 levels, 1 to 255 seconds
Operating Temperature
  • -40°C to +70°C (-40°F to +158°F)
Relative Humidity
  • 10% to 95% @ +40°C, non-condensing
Vibration
  • N/A
Dimensions (W x D x H)
  • 310 x 61.5 x 214 mm (12.20" x 2.42" x 8.43")
Weight (net/gross)
  • 2.6kg (5.73lb)/4.4kg (9.7lb)
Certifications
  • CE, EN 50155, EN 50121-3-2, EN 61373, EN 45545-2, UIC-612(keypads) complied
EOS
  • Windows® 10, Windows® 10 (IoT), Windows® 8/8.1, WE8S, Windows® 7, WES 7
Mounting
  • Suspension mount
  • VESA mount
  • GOT710S-837-R-E3845-24-110VDC (P/N-E22B710110)
  • 10.4" SVGA railway fanless touchscreen panel PC with Intel® Atom® E3845, sunlight-readable LCD (1000 nits), 5-wire resistive touchscreen, 24 to 110 VDC power input, EN 50155 Class S3 20ms power interruption protection
  • GOT710S-837-R-E3845-24-110VDC with keypad (P/N-E22B710111)
  • 10.4" SVGA railway fanless touchscreen panel PC with Intel® Atom® E3845, sunlight-readable LCD (1000 nits), 5-wire resistive touchscreen, 24 to 110 VDC power input, EN 50155 Class S3 20ms power interruption protection and keypad
  • 822B7100140E
  • GOT710 3G+GPS kit
  • 8812B7100A0E
  • GOT710 Wi-Fi Kit
  • 594B8122820E
  • M12 A-coded USB cable
  • 594B7102100E
  • RS-232 cable
  • 594B7102700E
  • M12 X-coded LAN cable
  • 594B7100B00E
  • M12 DC-in power cable with ACC signal, length 1.8M
