GOT610-837

LCD Panel	10.4" XGA TFT LCD 500 nits 1024 x 768 pixels
CPU	Intel® Atom® processor E3845 1.91 GHz
Chipset	SoC integrated
System Memory	4GB (default) or 8GB DDR3 memory onboard
BIOS	AMI
COM	1 x RS-232/422/485 with isolated 1.5KV (D-sub 9 male)
USB	4 x USB 2.0 type A
Ethernet	1 x 10/100/1000 Mbps with isolated 1.5KV
Display	N/A
Audio	1 x Audio (Line-out & Mic-in)
Storage	16GB flash onboard 1 x mSATA
Expansion	1 x SIM socket 2 x PCI Express Mini Card slot
Others	1 x DIO (6-in/2-out) with isolated 1.5KV 1 x CAN bus with isolated 1.5KV 1 x DC for power input with isolated 1.5KV 3 x Internal antenna (SMA)
Touchscreen	5-wire resistive touch or projected capacitive touch
Front Bezel	IP65, NEMA 4 rugged protection, aluminum front bezel
Power Supply	9 to 60 VDC
Power Comsumption	44.5W
Watchdog Timer	255 levels, 1 to 255 sec.
Operating Temperature	-30°C to +55°C (-22°F to +131°F)
Relative Humidity	10% to 95% @ 40°C, non-condensing
Vibration	TBD
Dimensions (W x D x H)	291 x 265.88 x 50 mm (11.46" x 10.47" x1.97")
Weight (net/gross)	2.05 kgs (4.52 lb)
Certifications	EN 60721-3-5
EOS	Windows® 7, Windows® 8/8.1, Windows® 10, WES 7, WE8S, Windows® 10 IoT
Mounting	Wall mount VESA arm Desktop stand

GOT610-837

10.4" XGA fanless touch panel computer with Intel® Atom® E3845, 5-wire resistive touch screen and 9 to 60 VDC power input
