GOT815-834

15" XGA TFT IP66 & IP69K-rated Stainless Steel Fanless PCT (or Resistive Touch) Panel Computer with Intel® Atom® Process

  • 15" XGA TFT LCD flat bezel projected capacitive (or resistive) touch
  • IP66/IP69K-rated (NEMA 4X) water/dust/corrosion-proof design
  • Full stainless steel enclosure with type 316
  • -20°C to +55°C wide operating temperature range
  • Fanless system with Intel® Atom® processor E3827
  • Optional Wi-Fi/3G kit for wireless network connectivity
  • 9 to 36 VDC wide range power input
  • M12 type I/O connectors for harsh environments

The GOT815-834, a streamline 15-inch stainless steel panel computer features a multi-touch and full flat front bezel. The ruggedized GOT815-834 supports the dual cores Intel® Atom® processor E3827 at 1.75 GHz and one DDR3L SO-DIMM with up to 8GB. This all-in-one industrial-grade touch panel PC is equipped with a 15-inch TFT XGA LCD with 420 nits high brightness and offers projected capacitive touch screen or flat resistive touch screen. Its secured design, fanless and noiseless advantages, and IP66-rated waterproof enclosure keep the entire panel system working efficiently and reliability in harsh environments against hazards including dust, dirt, water, oil, and chemicals. The newest stylish GOT815-834 is an excellent human machine interface platform for applications in food and chemical industries, pharmaceutical industry, transportation and oil pipeline monitoring.

LCD Panel
  • 15" XGA TFT LCD
  • 420 nits
  • 1024 x 768 pixels
CPU
  • Intel® Atom® processor E3827 1.75 GHz (Bay Trail)
Chipset
  • SoC integrated
System Memory
  • 1 x 204-pin SO-DIMM DDR3L-1333, up to 8 GB
BIOS
  • AMI
COM
  • 2 x RS-232/422/485 (default RS-232, M12 A-Coded)
USB
  • 4 x USB 2.0 (M12 A-Coded)
Ethernet
  • 1 x 10/100/1000 Mbps (M12 X-Coded)
Display
  • N/A
Audio
  • N/A
Storage
  • 1 x 2.5" SSD
  • 1 x CFast™
Expansion
  • 2 x PCI Express Mini Card slot
Others
  • Waterproof, dust proof ventilation valve
Touchscreen
  • 5-wire resistive touch or projected capacitive multi-touch
Front Bezel
  • Stainless type 316
Power Supply
  • 9 to 36 VDC
Power Comsumption
  • 30W
Watchdog Timer
  • 255 levels, 1 to 255 sec.
Operating Temperature
  • -20°C ~ +55°C (-4°F ~ +131°F)
Relative Humidity
  • 10% to 95% @ +40oC, non-condensing
Vibration
  • 2G, 5 - 500Hz, random for 2.5" SSD
  • 2G, 5 - 500Hz, random for CompactFlash™
Dimensions (W x D x H)
  • 382 x 55 x 305 mm (15.4" x 2.17" x 12.01")
Weight (net/gross)
  • 5.2kg (11.46lb)/ 8.4kg (18.51lb)
Certifications
  • CE
EOS
  • Windows® 10, Windows® 8/8.1, WES 8, Windows® 7, WES 7
Mounting
  • Suspension
  • VESA mount
  • GOT815-834-C-DC
  • 15" XGA fanless IP66-rated stainless steel touch panel computer with Intel® Atom® E3827, projected capacitive touch screen, flat bezel design and 9 to 36 VDC power input
  • GOT815-834-C-RF-DC
  • 15" XGA fanless IP66-rated stainless steel touch panel computer with Intel® Atom® E3827, projected capacitive touch screen, flat-bezel design, 9 to 36 VDC power input and Wi-Fi or 3G
  • GOT815-834-R-DC
  • 15" XGA fanless IP66-rated stainless steel touch panel computer with Intel® Atom® E3827, 5-wire flat resistive touch screen, flat bezel design and 9 to 36 VDC power input
  • GOT815-834-R-RF-DC
  • 15" XGA fanless IP66-rated stainless steel touch panel computer with Intel® Atom® E3827, 5-wire flat resistive touch screen, flat-bezel design, 9 to 36 VDC power input and Wi-Fi or 3G
  • 594B8122100E
  • Water-proof COM cable (1.8 m)
  • 594B8122820E
  • Water-proof USB cable (1.8 m)
  • 594B8152710E
  • Water-proof LAN cable (1.8 m)
  • 50966D45010E
  • Adapter 24V 120W. M12 A-code 5P. LTE120ES
  • 822B8120070E
  • GOT812 keyboard bracket (with keyboard)
