GOT5153W-834

15.6" WXGA TFT Fanless Touch Panel Computer with Intel® Celeron® Processor J1900



  • 15.6" WXGA wide screen TFT LCD display with LED backlight
  • 15.6" projected capacitive touch or 5-wire flat resistive touch
  • Fanless design with Intel® Celeron® processor J1900
  • 2.5" SATA HDD & CFast™ or mSATA
  • 2 GbE LAN, 4 USB, 2 COM and speakers
  • IP65 front bezel and IPX1 full enclosure
  • Supports desktop stand
  • Supports optional RFID or smart card reader

Datasheed (PDF)



The GOT5153W-834, a 15.6-inch WXGA TFT LCD fanless touch panel computer supports the high performance Intel® Celeron® J1900 quad-core processor. This all-in-one industrial touch panel PC has a stylish and slim industrial design with a 59 mm thickness, allowing for easy installation in a space-constrained environment. The GOT5153W-834 has the IPX1-compliant chassis and IP65-rated spill and dust resistant front panel to ensure the system operates reliably and stability in harsh environments. With a patented chassis, the touch panel PC offers an excellent thermal solution that dissipates heat efficiently. The widescreen panel computer has five membrane switches on its front panel, aiming to provide end-users with enhanced convenience for control of the system’s LCD on/off function, brightness, volume setting and more. With all of these features, this sleek and feature-rich system is ideal for a variety of applications including human-machine interface, digital signage, hotel/airport check-in/out kiosks, self-service restaurant’s ordering stations, building visitor controls and any IoT-related applications.



LCD Panel
  • 15.6" WXGA TFF LCD backlight
  • 300 nits
  • 1366 x 768 pixels
CPU
  • Intel® Celeron® processor J1900
Chipset
  • SoC integrated
System Memory
  • 1 x 204-pin SO-DIMM DDR3L-1333, up to 8 GB
BIOS
  • AMI
COM
  • 2 x RS-232/422/485 (default RS-232)
USB
  • 2 x USB 2.0
  • 2 x USB 3.0
Ethernet
  • 2 x 10/100/1000 Mbps (Intel® i210IT)
Display
  • 1 x VGA
Audio
  • Line-out
Storage
  • 1 x 2.5" SATA HDD (7-9.5 mm height)
  • 1 x CFast™ or mSATA
Expansion
  • 1 x full-size PCI Express Mini Card slot with mSATA
  • 1 x full-size PCI Express Mini Card slot with SIM
Others
  • 1 x Switch for power on/off
Touchscreen
  • Projected capacitive multi-touch
  • 5W flat resistive touch
Front Bezel
  • IP65, NEMA 4 rugged protection, plastic front bezel
Power Supply
  • DC version: 9 - 36VDC with over-current protection fuse
  • AC version: 100 - 240V AC-DC, 60W power adapter
Power Comsumption
  • 36W
Watchdog Timer
  • 255 levels, 0 ~ 255 sec.
Operating Temperature
  • 0°C ~ +45°C (32°F ~ +113°F)
Relative Humidity
  • 20% ~ 90% @ 40°C; non-condensing
Vibration
  • 2G, 10 ~ 500Hz, random for CFast™
Dimensions
(W x D x H)
  • 394.2 x 57 x 257.2 mm (15.53" x 2.25" x 10.13")
Weight (net/gross)
  • 3.0 kg (6.61 lb)/ 4.5 kg (9.92 lb)
Certificate
  • CE
EOS
  • Windows® 8.1, WE8S, Windows® 7, WES 7
  •
Mounting
  • Wall mount
  • VESA arm
  • Desktop stand



  • GOT5153W-834-PCT-J

          15.6" WXGA fanless touch panel computer with Intel® Celeron® processor J1900, projected capactive multi-touch screen, AC-DC 60W power adapter (screw type connector) and EMI class B

  • GOT5153W-834-FR-J

          15.6" WXGA fanless touch panel computer with Intel® Celeron® processor J1900, 5-wire flat resistive touch screen, AC-DC 60W power adapter (screw type connector) and EMI class B

  • GOT5153W-834-PCT-DC

          15.6" WXGA fanless touch panel computer with Intel® Celeron® processor J1900, projected capactive multi-touch screen, and 9 ~ 36 VDC power input (terminal block connector)

  • GOT5153W-834-FR-DC

          15.6" WXGA fanless touch panel computer with Intel® Celeron® processor J1900, 5-wire flat resistive touch screen, and 9 ~ 36 VDC power input (termincal block connector)

  • GOT5153W-834-PCT-J w/o OSD

          15.6" WXGA fanless touch panel computer with Intel® Celeron® processor J1900, projected capactive multi-touch screen, w/o membrane keys, AC-DC 60W power adapter (screw type connector) and EMI class B

  • GOT5153W-834-FR-J w/o OSD

          15.6" WXGA fanless touch panel computer with Intel® Celeron® processor J1900, 5-wire flat resistive touch screen, w/o membrane keys, AC-DC 60W power adapter (screw type connector) and EMI class B

  • GOT5153W-834-PCT-DC w/o OSD

          15.6" WXGA fanless touch panel computer with Intel® Celeron® processor J1900, projected capactive multi-touch screen, w/o membrane keys, 9 ~ 36 VDC power input (terminal block connector)

  • GOT5153W-834-FR-DC w/o OSD

          15.6" WXGA fanless touch panel computer with Intel® Celeron® processor J1900, 5-wire flat resistive touch

  • screen, w/o membrane keys, 9 ~ 36 VDC power input (termincal block connector)
  • Wi-Fi + Bluetooth kit
  • E226171106

          Stand kit

  • 881251203A0E

          RFID kit
