GOT5100T-845

GOT5100T-845 10.4" XGA/SVGA TFT Fanless Touch Panel Computer with Intel® Celeron® Processor N3060

  • 10.4" XGA/SVGA TFT LCD display with LED backlight
  • Fanless design with Intel® Celeron® processor N3060
  • 2 GbE LAN, 4 USB and 2 COM
  • Plastic and IP65-rated front bezel
  • Supports RFID (optional)
  • External AT/ATX mode selection switch
  • Easy access storage design
  • Supports optional panel mount/wall mount/VESA arm/desktop stand
  • Adjust RS-232/422/485 setting via BIOS

Datasheed (PDF)

The GOT5100T-845, a power-efficient 10.4” fanless touch panel computer, features Intel® Celeron® N3060 dual-core processor (up to 2.48 GHz). This cost-effective industrial touch panel PC offers options of XGA color resolution 1024 x 768 TFT LCD display with brightness 350 nits or SVGA color resolution 800 x 600 TFT LCD display with brightness 400 nits. With its modern, extremely light weight and fanless design, the GOT5100T-845 is well-suited for use in shopping malls and supermarkets as a self-service kiosk and in smart factory automation, medical & healthcare industry, and building automation applications.

LCD Panel
  • 10.4" XGA/SVGA TFT LCD with LED backlight
  • 350 nits (XGA)
    400 nits (SVGA)
  • 1024 x 768 (XGA)
    800 x 600 (SVGA)
CPU
  • Intel® Celeron® processor N3060 (up to 2.48 GHz)
Chipset
  • SoC integrated
System Memory
  • 1 x 204-pin SO-DIMM DDR3L-1600 MHz, up to 8 GB
BIOS
  • AMI
COM
  • 1 x RS-232
  • 1 x RS-232/422/485 (default RS-232)
USB
  • 2 x USB 2.0
  • 2 x USB 3.0
Ethernet
  • 2 x 10/100/1000 Mbps (Intel® i211AT)
Display
  • 1 x HDMI
Audio
  • 1 x Audio (Line-out)
Storage
  • 1 x 2.5" SATA HDD (9.5 mm)
  • 1 x mSATA
Expansion
  • 1 x Full-size PCI Express Mini Card slot with mSATA
  • 1 x Full-size PCI Express Mini Card slot with SIM
Others
  • 1 x Switch for power On/Off
  • 1 x AT/ATX mode selection switch
Touchscreen
  • Resistive type
Front Bezel
  • IP65, NEMA 4 rugged protection, plastic front bezel
Power Supply
  • AC version: 100 - 240VAC-DC, 60W power adapter or
  • DC version: 24 VDC with over current protection fuse
Power Comsumption
  • 32W
Watchdog Timer
  • 255 levels, 0 to 255 sec.
Operating Temperature
  • 0°C to +50°C (+32°F to +122°F) (with W.T. DRAM/HDD in airflow condition)
  • 0°C to +45°C (+32°F to +113°F) (with W.T. DRAM/HDD)
Relative Humidity
  • 20% - 90% @ +40°C; non-condensing
Vibration
  • 2G, 5 - 500Hz, random for SSD
Dimensions
(W x D x H)
  • 292.5 x 45.8 x 235.8 mm (11.52" x 1.80" x 9.28")
Weight (net/gross)
  • 1.8 kg (3.96 lb)/3 kg (6.61 lb)
Certifications
  • CE, FCC, UL60950-1
EOS
  • WES 7, Windows® 7, WE8S (64-bit), Windows® 8.1 (64-bit), Windows® 10
Mounting
  • Panel mount
  • Wall mount
  • VESA arm
  • Desktop stand
  • GOT5100T-845-J
  • 10.4" SVGA fanless touch panel computer with Intel® Celeron® processor N3060, 5-wire resistive touch screen, AC-DC 60W power adapter (screw type connector) and EMI class A
  • GOT5100T-845-24VDC
  • 10.4" SVGA fanless touch panel computer with Intel® Celeron® processor N3060, 5-wire resistive touch screen and 24 VDC power input (terminal block connector)
  • GOT5100T-845-XGA-J
  • 10.4" XGA fanless touch panel computer with Intel® Celeron® processor N3060, 5-wire resistive touch screen, AC-DC 60W power adapter (screw type connector) and EMI class A
  • GOT5100T-845-XGA-24VDC
  • 10.4" XGA fanless touch panel computer with Intel®Celeron® processor N3060, 5-wire resistive touch screen and 24 VDC power input (terminal block connector)
  • Wi-Fi + Bluetooth kit
  • Speaker kit
  • 881281021A0E
  • Panel mount kit
  • 881251001A0E
  • VESA mount kit
  • E226171106
  • Stand kit
  • 881251203A0E
  • RFID kit
